TDEAHf丨CAS 19824-55-6

CAS: 19824-55-6
Abbreviation: TDEAHf

Tetrakis(diethylamino)hafnium, also known as TDEAH or TDEAHf, is a moisture-sensitive liquid hafnium amide used as a hafnium source in ALD, CVD and MOCVD processes. It has been widely investigated for the deposition of HfO₂ high-k dielectric films and hafnium-containing mixed oxides.
Availability:

Tetrakis(diethylamino) hafnium Basic Properties

Synonyms

HAFNIUM DIETHYLAMIDE;TETRAKIS(DIETHYLAMINO)HAFNIUM, 99.99%;tetrakis(diethylamido)hafnium(iv); Tetrakis(diethylamino)hafnium 99.999%

Molecular Formula

C₁₆H₄₀HfN₄

Appearance

Pale yellow liquid

Molecular Weight

467.01

Melting Point

-68 ℃

Boiling Point

130 ℃ 0.01 mm Hg(lit.)

Density

1.249 g/mL at 25 °C(lit.)

Flash Point

10 ℃

Sensibility

Moisture sensitive

Purity

≥99%,Hf-99.9999%

Analytical Methods

ICP-MS /ICP-OES /relevant assay method

Package Information

100g, 500g, 1kg, or customized

Why Tetrakis(diethylamino) hafnium?

Tetrakis(diethylamino)hafnium is a homoleptic hafnium(IV) amide in which the hafnium center is coordinated to four diethylamino ligands. Unlike solid-state hafnium precursors such as HfCl₄ or certain forms of TDMAH, TDEAH exists in a liquid state under ambient operating conditions.

TDEAH has a relatively moderate vapor pressure and requires controlled heating for vapor-phase delivery. Its molecular structure contains no chlorine, making it a chlorine-free hafnium source—ideal for processes where the introduction of chlorine from a metal precursor is undesirable.

What Matters When Evaluating TDEAH?

Zirconium Content

Hafnium and zirconium exhibit very similar chemical properties and frequently coexist within hafnium-based raw material systems. Consequently, the zirconium (Zr) content is typically specified as an independent parameter for commercial high-purity hafnium precursors.

If a thin-film process imposes strict requirements on zirconium concentration, the specific limits should be clearly defined when requesting quotes from suppliers and subsequently verified via the product’s Certificate of Analysis (COA).

Moisture Control

TDEAH is highly sensitive to moisture and reacts with water. Therefore, containers, delivery systems, and sampling environments must be kept dry. Repeated exposure to humid air can alter the composition of the precursor, even if no obvious change in the liquid's appearance is observed.

TDEAH for ALD and CVD

TDEAH is a hafnium precursor used in ALD and CVD processes for the deposition of hafnium-containing thin films.

Its primary applications include:

  • HfO₂ thin films for high-k dielectric applications

  • Hafnium-based mixed oxides, including HfAlOₓ and hafnium silicates

  • Semiconductor process development involving hafnium-containing dielectric layers

  • Evaluation of ALD/CVD precursors for advanced thin-film research and process optimization

Vapor Pressure and Precursor Delivery

The vapor pressure of TDEAH increases significantly with temperature; therefore, the temperatures of the precursor source and the delivery lines must be strictly controlled during operation.

TDEAH should not be exposed to excessively high temperatures for extended periods. A well-designed precursor delivery system should be capable of providing an adequate supply of precursor vapor while minimizing the duration for which the precursor is subjected to heat.

Package and Delivery

TDEAH is sensitive to moisture and should be supplied in sealed packaging suitable for air-sensitive precursor materials.

Available packaging options include:

  • Sealed bottles or ampoules

  • Stainless steel precursor containers

  • ALD/CVD bubblers

  • Customized container and valve configurations

Packaging specifications and fill volumes can be tailored to laboratory, pilot, or production-scale deposition systems.

Storage and Handling

  1. Store in a dry, tightly closed container.

  2. Minimize exposure to air and moisture during sampling or transfer.

  3. Use dry inert-atmosphere handling where required.

  4. Keep containers and transfer equipment dry before use.

  5. Avoid unnecessary prolonged heating during storage.

  6. Reseal the container promptly after use.

FAQ

1. What is the ALD temperature window for TDEAH?

There is no single, universal ALD temperature window for TDEAH; it is approximately 200–275 °C. Results may vary depending on the specific co-reactants, substrates, and reactor configurations used.

2. Does TDEAH have a high vapor pressure?

TDEAH is sufficiently volatile for use in vapor deposition, though its vapor pressure is lower than that of several other hafnium precursors. Its vapor pressure is approximately 0.04 Torr at 70 °C and about 0.4 Torr at 100 °C.

3. Is it possible to increase the delivery rate of TDEAH by further raising its heating temperature?

While increasing the temperature raises the vapor pressure, prolonged exposure to high temperatures is undesirable. Under specific test conditions, TDEAH undergoes partial decomposition at temperatures between 120 °C and 150 °C. Therefore, the delivery temperature and residence time should be optimized in conjunction with one another.

4. Does Wolfa offer customized packaging?

Yes. In addition to our standard specifications, we can discuss tailored filling and packaging solutions based on specific quantities and the delivery requirements for your precursors.

For product analysis reports (such as COA) or procurement consulting, please feel free to contact us at jomin@wolfachem.com at any time.

If you would like to obtain the COA for this product, simply send an email to jomin@wolfachem.com. You will then receive it.
